hansgrohe Activera SShowerpipe 240 1jet EcoSmart with bath thermostat Ecostat Fine
Product code 28871000
Please try again.
Article features
- consists of: overhead shower, hand shower, thermostatic shower mixer, shower rail, slider, shower hose
- overhead shower Activera S 240 1 jet
- shower head size overhead shower: 240 mm
- spray type overhead shower: Rain
- spray disc surface: graphite
- removable shower head
- flow regulator: 8 l/min (with possible tolerances -20%)
- spray type hand shower: Rain, ImpactRain
- flow rate of hand shower at 3 bar: 7.1 l/min
- maximum flow rate for Showerpipe at 3 bar: 8 l/min
- min. operating pressure: 1 bar
- max. operating pressure: 10 bar
- FlexPower: nozzles automatically adjust to water pressure by opening and closing
- convenient spray selection via Select button on the hand shower
- QuickClean+: avoid limescale deposits thanks to the elasticity of the nozzles
- overhead shower angle adjustable
- height-adjustable slider with locking push-button slider
- slider rotatable on the pipe for left or right operation
- shower arm length overhead shower: 344 mm
- thermostatic mixer Ecostat Fine
- SafetyStop at 40°C
- adjustable hot water limitation
- temperature and water flow control
- Outlets may not be operated simultaneously
- exposed installation
- connection thread: G ½
- centre distance: 150 ± 12 mm
- intrinsically safe against backflow
- shower rail diameter: 22 mm
- 3 outlets
Consists of
Downloads
Planning data
BIM data
Technical drawings
Innovative technologies
Always constant water temperature
Want to save water? With pleasure!
Great showering pleasure
Intuitive jet adjustment
Effectively prevents annoying limescale buildup
Safety lock at over 40 °C
Angle-adjustable overhead shower
FlexPower - Top performance with less water
For mindful use of water
Thermostat
Always constant water temperature
Safe and reliable: The thermostat with integrated temperature control continuously monitors the water temperature while showering or bathing. It reacts quickly to changes in pressure and keeps the temperature comfortably at a constant level. For pleasant water enjoyment at all times.
EcoSmart
Want to save water? With pleasure!
Enjoy shower pleasure using less water thanks to our EcoSmart technology. The products convince with a maximum flow rate of 8 l/min thanks to a flow limiter. Can help in reducing water and energy costs every day.
XXL Performance
Great showering pleasure
XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.
Select
Intuitive jet adjustment
The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.
QuickClean+
Effectively prevents annoying limescale buildup
Elastic silicone nozzles constantly open and close preventing limescale build-up. Innovative technology for long-lasting water enjoyment with less cleaning and maintenance.
SafetyStop
Safety lock at over 40 °C
A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.
Adjustable Shower Head
Angle-adjustable overhead shower
The angle of the overhead shower can be tilted so that the shower rain is adjusted to suit the specific shower area or a person’s height. The water sprays can then work their feel-good magic and envelop the whole body.
FlexPower
FlexPower - Top performance with less water
Innovative technology that provides great shower comfort with low consumption. Elastic nozzles in the shower head dynamically adapt to the water flow and pressure, increasing the performance of the spray and enabling more efficient use of water.
Spray Types
