AXOR Montreux4-hole tile mounted bath mixer with cross handles


Product code 16544000
Please try again.
Please try again.
Article features
- Consists of: 3-hole tile mounted bath mixer, hand shower, shower hose, shower holder
- designed to run 2 outlets
- spout 196 mm long
- Spray type mixer: normal spray
- Spray type hand shower: RainAir
- Maximum pull-out length of hand shower: 1.10 m
- Maximum flow rate (at 3 bar): 21 l/min
- Flow rate for bath spout (at 3 bar): 21 l/min
- Flow rate of hand shower (at 3 bar): 15 l/min
- ceramic valves hot / cold 180°
- Non-return valve
- Noise class: I
- Connection type: basic set
- Min. operating pressure: 1 bar
- Max. operating pressure: 10 bar
Downloads
Technical drawings
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Further Parts are required
Required parts
Optional accessories
Spare parts for build year 04/06
To the online spare parts shopItem no. | DescriptionProduct codeDescription and article no. |
---|
a | SECUFLEX hose + long hose (max. extension 1,40 m)94109000 |
b | concealed item14444180 |
c | concealed item14445180 |
d | silicone sprayer 10 ml97864000 |
e | Grease90920000 |
1 | spout cpl.98606000 |
2 | aerator M22x1 (25 l/min)98575000 |
3 | diverter knob98607000 |
4 | hollow set screw M6x697660000 |
5 | handle16291000 |
6 | set of screw covers, cold / hot water / neutral97987000 |
7 | O-ring 16x298133000 |
8 | escutcheon98605000 |
9 | selector96777000 |
10 | guide tube92214000 |
11 | O-ring 20x1,598197000 |
12 | O-Ring 14x2,598189000 |
13 | O-Ring 23x2,598183000 |
14 | O-Ring 22x298185000 |
15 | O-ring 9x2,598217000 |
16 | flange97656000 |
17 | selector housing97225000 |
18 | O-ring 58x398202000 |
19 | handshower16320000 |
20 | filter packing94246000 |
21 | shower holder, assy96433000 |
22 | escutcheon for shower holder96237000 |
23 | escutcheon chuck97105000 |
24 | nut97584000 |
25 | insert for shower holder96942000 |
26 | O-ring 38x2,598198000 |
27 | O-Ring 28x298194000 |
28 | shower hose 2,00 m94148000 |
29 | O-ring 11x298127000 |
30 | set of non return valves DW 1594074000 |
Innovative technologies
AirPower: more volume with added air
With this shower technology, Hansgrohe mixes water with air, and you feel pleasantly sparkling AirPower all over your skin. As water enriched with air makes the droplets plumper, lighter and softer. This means you use your water more efficiently.
QuickClean: Less limescale, more fun
Who likes cleaning? With QuickClean, limescale deposits and dirt on hansgrohe taps and showers disappear in an instant. Simply rub any dirt off the flexible silicone nozzles.
AirPower
AirPower: more volume with added air
With this shower technology, Hansgrohe mixes water with air, and you feel pleasantly sparkling AirPower all over your skin. As water enriched with air makes the droplets plumper, lighter and softer. This means you use your water more efficiently.
QuickClean
QuickClean: Less limescale, more fun
Who likes cleaning? With QuickClean, limescale deposits and dirt on hansgrohe taps and showers disappear in an instant. Simply rub any dirt off the flexible silicone nozzles.
Spray Types
Gentle air-enriched rainfall.
RainAir
Gentle air-enriched rainfall.
Five-year manufacturer’s guarantee
5
year manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
