hansgrohe Metris M71Single lever kitchen mixer 320, single spray mode
Product code 14822000
Product saved for 30 days.To the product comparison
The article could not be saved.
Please try again.
Please try again.
Article features
- ComfortZone 320 provides space for greater freedom of movement
- L-spout
- Swivel spout can be adjusted in 3 steps 110°, 150° or 360°
- laminar spray
- Maximum flow rate (at 3 bar): 12 l/min
- ceramic cartridge
- ⅜" hose connections
- operating pressure: min. 1 bar / max. 10 bar
- Significantly reduced splashing by soft start of the water flow
- WRAS 1903006
Downloads
Technical drawings
Spare parts for build year 02/15
| Item no. |
|---|
| a | set of locating rings (60° / 80°)92259000 |
| 1 | spout cpl.98454000 |
| 2 | aerator laminar M24x1 (15 l/min)92517000 |
| 3 | screw cover95181000 |
| 4 | set of locating rings (110° / 150°)98486000 |
| 5 | sealing set92646000 |
| 6 | O-Ring 14x2,598189000 |
| 7 | O-ring 11x392481000 |
| 8 | screw97662000 |
| 9 | axialring97558000 |
| 10 | handle98455000 |
| 11 | screw cover96338000 |
| 12 | flange95498000 |
| 13 | nut97209000 |
| 14 | O-Ring 32x298193000 |
| 15 | cartridge, assy92730000 |
| 16 | locking screw for handle95140000 |
| 17 | seal95008000 |
| 18 | seal92582000 |
| 19 | support97523000 |
| 20 | fixing set (Ø 34)95049000 |
| 21 | lever collar97548000 |
| 22 | connection hose 900 mm M8x0,75 G3/896316000 |
| 23 | O-ring 7x1,598422000 |
| 24 | sealing set95581000 |
Innovative technologies
For more space at the kitchen sink
Used to describe the generous space created between the kitchen tap and the sink - vertically and horizontally. These high-quality taps are highly user-friendly and have a flexible swivel range. For maximum freedom of movement.
ComfortZone
For more space at the kitchen sink
Used to describe the generous space created between the kitchen tap and the sink - vertically and horizontally. These high-quality taps are highly user-friendly and have a flexible swivel range. For maximum freedom of movement.
Spray Types
Crystal-clear spray type with no added air for the sink. This spray is a great help when going through the day-to-day kitchen routine, e.g. quickly filling large pots or bowls. Efficient with very little splashback.
Five-year manufacturer’s guarantee
5
year manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
