AXOR MontreuxThermostatic shower mixer for exposed installation with cross handle

View in AR
360° View
{{points}}
Secure your talismans for this product.
as of
Product code 16261000
Add to notepad
Product noted
Product saved for 30 daysSee notepad
The product could not be saved.
Please try again.
Please try again.
Compare products
Product added
Product saved for 30 daysTo the product comparison
The article could not be saved.
Please try again.
Please try again.
Log in now
As a logged in user, you can see additional information, such as price lists and picture self service.
Article features
- designed to run 1 function
- wall-mounted
- Maximum flow rate (at 3 bar): 16 l/min
- thermostat cartridge, ceramic valve 180°
- safety stop at 40°C
- Maximum temperature can be adjusted on installation
- Non-return valve
- Connection type: S connections
- Centre distance: 150 mm ± 12 mm
- Min. operating pressure: 1 bar
- Max. operating pressure: 10 bar
- Noise class: I
- Kiwa UK 1507713
Downloads
Technical drawings
Certificates


TMV3 - A thermostatic mixing valve with enhanced thermal performance, complying with NHS Estates requirements.
The TMV3 Scheme is the third party valve accreditation programme administered by Buildcert. It is an independent test to check if the submitted valves are suitable for use in high risk commercial healthcare applications in the UK.

Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 09/19
To the online spare parts shopItem no. | DescriptionProduct codeDescription and article no. |
---|
a | pushbutton92848000 |
1 | handle for thermostat39398000 |
2 | screw cover98906000 |
3 | safety set for temperature control95041000 |
4 | thermostat cartridge94282000 |
5 | O-ring 14x298129000 |
6 | handle16396000 |
7 | set of screw covers, cold / hot water / neutral97987000 |
8 | shut off unit94149000 |
9 | set of nuts96157000 |
10 | non return valve (pressure-resistant up to 2 MPa)93136000 |
11 | non return valve96737000 |
12 | O-ring 17x1,598137000 |
13 | filter packing96922000 |
14 | escutcheon98595000 |
15 | noise reduction96429000 |
16 | set of S-unions (±12 mm)94140000 |
17 | handle98920000 |
Five-year manufacturer’s guarantee
5
year manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
