hansgrohe EcostatThermostatic shower mixer Comfort for exposed installation hotel quality
Product code 13113000
Product saved for 30 days.To the product comparison
The article could not be saved.
Please try again.
Please try again.
Article features
- designed to run 1 outlet
- volume control for 1 function
- ceramic valve 180°, thermostat cartridge
- Maximum flow rate (at 3 bar): 17 l/min
- Min. operating pressure: 1 bar
- Max. operating pressure: 10 bar
- Safety stop at 40°C
- Maximum temperature can be adjusted on installation
- Non-return valve
- Material handles: metal
- Centre distance: 150 mm ± 12 mm
- Connection type: S connections
- dirt filter included
- Noise class: I
- WRAS 1904006
- EPD_20230023_Thermostats
Downloads
Technical drawings
Certificates
TMV3 - A thermostatic mixing valve with enhanced thermal performance, complying with NHS Estates requirements.
The TMV3 Scheme is the third party valve accreditation programme administered by Buildcert. It is an independent test to check if the submitted valves are suitable for use in high risk commercial healthcare applications in the UK.
Spare parts for build year 07/12
| Item no. |
|---|
| a | set of S-unions (±32 mm)98592000 |
| b | brake disc92469000 |
| 1 | handle95836000 |
| 2 | pushbutton92848000 |
| 3 | handle fixing set95843000 |
| 4 | safety set95839000 |
| 5 | nut98913000 |
| 6 | O-ring 26x1,598390000 |
| 7 | thermostat cartridge98282000 |
| 8 | cartridge for exchanged connections92373000 |
| 9 | connecting thread95392000 |
| 10 | O-ring 14x298129000 |
| 11 | handle95845000 |
| 12 | safety set95841000 |
| 13 | shut off unit94149000 |
| 14 | set of nuts96157000 |
| 15 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 16 | non return valve96737000 |
| 17 | O-ring 17x1,598137000 |
| 18 | filter packing96922000 |
| 19 | escutcheon Ø 68 mm96467000 |
| 20 | noise reduction96429000 |
| 21 | set of S-unions (±12 mm)94140000 |
Innovative technologies
For mindful use of water
he amount of water can be precisely adjusted via a control dial on the water-saving thermostat control, enabling you to use less water every day. Ideal also for children, who usually prefer gentle flow of water anyway.
Always constant water temperature
Safe and reliable: The thermostat with integrated temperature control continuously monitors the water temperature while showering or bathing. It reacts quickly to changes in pressure. For pleasant water enjoyment at all times.
Safety lock at over 40 °C
A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.
Water flow control
For mindful use of water
he amount of water can be precisely adjusted via a control dial on the water-saving thermostat control, enabling you to use less water every day. Ideal also for children, who usually prefer gentle flow of water anyway.
Thermostat
Always constant water temperature
Safe and reliable: The thermostat with integrated temperature control continuously monitors the water temperature while showering or bathing. It reacts quickly to changes in pressure. For pleasant water enjoyment at all times.
SafetyStop
Safety lock at over 40 °C
A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.
Five-year manufacturer’s guarantee
5
year manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
