hansgrohe Croma Select SShowerpipe 280 1jet with thermostat and hand shower Raindance Select S 120 3jet
Product code 26890700
Product saved for 30 days.To the product comparison
The article could not be saved.
Please try again.
Please try again.
Article features
- Consists of: overhead shower, hand shower, Thermostatic shower mixer, shower hose, slider, shower bar
- overhead shower Croma 280
- shower head size overhead shower: 280 mm
- spray type overhead shower: RainAir
- flow rate RainAir 15 l/min at 3 bar
- flow rate Rain 11 l/min at 3 bar
- spray type hand shower: RainAir, Rain, Whirl
- Flow rate of hand shower (at 3 bar): 14.5 l/min
- Maximum flow rate for Showerpipe at 3 bar: 15 l/min
- Min. operating pressure: 1 bar
- Max. operating pressure: 10 bar
- overhead shower angle adjustable
- pipe can be shortened in height
- Shower bar diameter: 22 mm
- height-adjustable hand shower holder
- shower arm length overhead shower: 400 mm
- Swivel shower arm
- thermostat Ecostat Comfort
- safety stop at 40°C
- adjustable hot water limitation
- outlets controlled via volume control/diverter and may not be used simultaneously
- exposed design allows easy installation, all working parts are outside of the wall
- Connection dimension 1/2"
- Connection thread ½"
- Centre distance 150 mm ± 12 mm
- Intrinsically safe against backflow
- designed to run 2 outlets
Consists of
Downloads
Planning data
Technical drawings
Spare parts for build year 06/20
| Item no. |
|---|
| 1 | mounting set96179000 |
| 2 | wall flange95688000 |
| 3 | tile-matching-disk 7 mm95239000 |
| 4 | escutcheon Ø 60 mm95692700 |
| 5 | O-ring 20x2,592602000 |
| 6 | screw92137000 |
| 7 | hollow set screw M6x598447000 |
| 8 | sleeve92166700 |
| 9 | shower arm95985700 |
| 10 | head shower26220700 |
| 11 | filter insert97708000 |
| 12 | ball joint98941700 |
| 13 | lock washer98942700 |
| 14 | nut97958700 |
| 15 | lever collar97536000 |
| 16 | seal97606000 |
| 17 | air jet (Eco)95795700 |
| 18 | O-ring 7x298419000 |
| 19 | O-ring 15x2,598131000 |
| 20 | pipe 1030 mm95915700 |
| 21 | noise reduction95009000 |
| 22 | O-ring 12x2,2598382000 |
| 23 | support, assy97651700 |
| 24 | handshower26530700 |
| 25 | shower hose Isiflex'B 1,60 m28276700 |
| 26 | seal98058000 |
| 27 | O-ring 14x298129000 |
| 28 | Thermostat92147700 |
| 29 | handle95836700 |
| 30 | pushbutton92848700 |
| 31 | handle fixing set95843000 |
| 32 | safety set95839000 |
| 33 | nut98913000 |
| 34 | O-ring 26x1,598390000 |
| 35 | thermostat cartridge98282000 |
| 36 | cartridge for exchanged connections92373000 |
| 37 | stop ring for flow control95927000 |
| 38 | shut off unit with selector98283000 |
| 39 | set of nuts96157700 |
| 40 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 41 | non return valve96737000 |
| 42 | filter packing96922000 |
| 43 | escutcheon Ø 68 mm96467700 |
| 44 | noise reduction96429000 |
| 45 | set of S-unions (±12 mm)94140000 |
| 46 | mounting set98716000 |
| 47 | O-Ring 50x298187000 |
| 48 | O-ring 20x298165000 |
Innovative technologies
Less limescale, more joy
Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.
Great showering pleasure
XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.
Intuitive jet adjustment
The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.
More pleasure, more efficiency
Mixes generous quantities of air into the water to create light, pearl-like droplets that caress the skin. The shower feels luxurious, even though little water is consumed. The spray causes less splash, reducing the time to clean the shower area.
QuickClean
Less limescale, more joy
Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.
XXL Performance
Great showering pleasure
XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.
Select
Intuitive jet adjustment
The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.
AirPower
More pleasure, more efficiency
Mixes generous quantities of air into the water to create light, pearl-like droplets that caress the skin. The shower feels luxurious, even though little water is consumed. The spray causes less splash, reducing the time to clean the shower area.
Spray Types
Gentle droplets enriched with air from the luxurious shower rain feel silky soft on the skin for an indulgent shower. Additionally, this spray type is efficient and thorough enough to rinse out shampoo.
Invigorating and energising everyday showering indulgence with a satisfyingly full shower rain. With its small outlets on the shower head, this spray type works efficiently to thoroughly rinse out shampoo.
Rotating water sprays to pleasantly shower away everyday tensions. Individual sprays of water flow around each other in a helical pattern, helping to relieve tension with their gentle massaging action.
Awards
Five-year manufacturer’s guarantee
5
year manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
